KJELLBERG PLASMA ONDERDELEN

PLASMA ONDERDELEN GESCHIKT VOOR KJELLBERG


PLASMA ONDERDELEN VOOR PB-S20W/WH - PB-S25W/WH - PB-S40W/WH
PB-S45W/WH - PB-S45W/WH-1 - PZ-S45W


Item No:

Omschrijving

1Shield cup
2Nozzle retaining cup 6.0
3Nozzle Ld 1.3, Air
Nozzle Le 1.4, Air
4O-Ring 12x1.5 Silicone (10 pcs)
5Swirl ring
6Electrode Kb , Air
7Electrode Kb-Xl O2 - Solid Silver - (replaces 11.828.021.3001)
8O-Ring 6x2 Silicone (10 pcs)
9Cooling tube
10Cooling tube
11O-Ring 20x2 Silicone (10 pcs)
12Nozzle retaining cup 5.0
13Nozzle Lb 1.0, Air
Nozzle Ld 1.3, Air
14Nozzle retaining cup 9.6
15Nozzle Lle 1.0, Air
Nozzle Lde 1.3, Air
Nozzle Lee 1.4, Air
16Nozzle Lk 2.5, Air
Nozzle Ln 3.0, Air
17Shield Cup
18Shield 4.0
18aO-Ring 22x1.5 Silicone
19Nozzle retaining cup
20Nozzle Lle -Xl 1.0, O2 (replaces 11.828.223.410)
Nozzle Lde-Xl 1.3, O2 (replaces 11.828.223.414)
Nozzle Lee-Xl 1.4, O2



PLASMA ONDERDELEN VOOR PERCUT 100

Kjellberg 1.jpg

Item No:

Omschrijving

1Shield Cup
2Shield 1.5
Shield 2.0
Shield 2.5
Shield 3.0
Shield 4.0
2aO-Ring 24x1.5 Silicone (10 pcs)
3Nozzle retaining cup 0.8
4Nozzle 0.6 O2
Nozzle 0.7 O2
Nozzle 0.8 O2
Nozzle 0.9 O2
Nozzle 1.0 O2
Nozzle 1.1 O2
Nozzle 1.2 O2
4aO-Ring 4x1 Silicone (10 pcs)
4bO-Ring 15x1.5 Silicone (10 pcs)
5Swirl ring
6Spacer ring
6aO-Ring 10x1 Silicone (10 pcs)
7Electrode O2 Xl Z012 - Solid Silver
7aO-Ring 6x2 Silicone (10 pcs)
8Cooling tube PerCut 100
9O-Ring 36x2 Silicone (10 pcs)
10O-Ring 20x2 Silicone
11Nozzle retaining cup 0.4
12Nozzle 1.2 O2
Nozzle 1.4 O2
13Swirl ring
14Electrode O2 Xl Z002 - Solid Silver
15Nozzle retaining cup
16Insulator
17Shield Cup



PLASMA ONDERDELEN VOORPERCUT 160i - HiFocus 160i


Item No:

Omschrijving

1O-Ring 20x2.0 Silicone (10 pcs)
2O-Ring 36x2.0 Silicone (10 pcs)
3Cooling tube PerCut 160i
4Electrode O2 X1 S002 - Solid Silver
4aO-Ring 6x2.0 Silicone (10 pcs)
5Electrode O2 X1 S012 - Solid Silver
6Electrode A S042
7Electrode A S052
8Swirl ring, Vespel Z101
Swirl ring, Vespel Z102
8aO-Ring 10x1.0 Silicone (10 pcs)
9Swirl ring, Vespel Z111
10Spacer ring
11Nozzle 0.6 S2006 - 25A
Nozzle 0.7 S2007 - 35A
Nozzle 0.8 S2008 - 50A
Nozzle 0.9 S2009 - 70A
Nozzle 1.0 S2010 - 80A
Nozzle 1.1 S2011
Nozzle 1.2 S2012 -90A
Nozzle 1.4 S2014 - 100A
Nozzle 1.6 S2016 - 130A
11aO-Ring 4x1.0 Silicone (10 pcs)
11bO-Ring 15x1.5 Silicone (10 pcs)
12Nozzle 1.2 S2112 - 100A
Nozzle 1.4 S2114 - 130A
Nozzle 1.6 S2116 - 160A
13Nozzle 1.4 S2514 - 100A
Nozzle 1.6 S2516 - 130A
Nozzle 1.8 S2518 - 160A
14Nozzle retaining cup 0.4 S3004
Nozzle retaining cup 0.8 S3008
Nozzle retaining cup 0.8 S3028
15Shield 1.5 Z4015
Shield 2.0 Z4020
Shield 2.2 Z4022
Shield 2.5 Z4025
Shield 3.0 Z4030
Shield 4.0 Z4140
15aO-Ring 24x1.5 Silicone (10 pcs)
16Shield 3.0 Z4530
Shield 4.0 Z4540
17Shield Cup


PLASMA ONDERDELEN VOOR PA-50 - PA-S75 - PA-S76 - PB-S77 - FineFocus 800 - 900 - 1600


Item No:

Omschrijving

1Electrode K2Air
Electrode K2XL - Solid Silver
2Swirl ring, Teflon
3Nozzle L3 Air - 120A
Nozzle L1 Air - 160A
Nozzle L2 Air - 250A
Nozzle L3 XL O2- 120A
Nozzle L1 XL O2 - 160A
Nozzle L2 XL O2 - 250A
4Nozzle retaining cup,conical 38mm
5Shield, Fiberglas

O-Ring48x2.0 Silicone (10 pcs)
6Shield Cup 4.0mm V4340
Shield Cup 4.5mm V4345
Shield Cup 5.0mm V4350
